Ventilated Facade Systems in Modern Design

INNOWOOD ALLFACE Natural Ventilated facade systems may also be referred to as rain-screens or double-skin facades as they have been developed to protect buildings against the combined action of rain and wind by counterbalancing the effects of water beating on walls and keeping the building dry.
Innowood ALLFACE Natural Ventilation façade, a high-energy efficient technical solution, offers high levels of thermal comfort contributing to energy savings (ranging 20-40% reduction of the overall building consumption). The investment costs for a refurbishment are, in the long term, remunerated by the reduction in mechanical use. The challenge is represented by the application on residential buildings.

INNOWOOD ALLFACE VENTILATED FACADE VISIBLE FIXING - RIVETS

INNOWOOD ALLFACE Ventilated Facade fixing utilises rivets and anchor clips as the fixing method. Rivets enable fast and permanent installation of facade cladding. The system is flexible and is designed to absorb thermal expansion and contraction of materials used.

Ventilation-Visble Fixing
Ventilation-Visble Fixing 2

INNOWOOD ALLFACE VENTILATED FACADE VISIBLE FIXING - CLIPS

Fixing with anchoring clips for INNOWOOD facade boards. The Anchoring clips are available in aluminium or stainless steel and can be made to match the colour of the facade elements.

Ventilation-Conceal Fixing 1

H

Internal Panel Dimensions External Panel Dimensions
1200 x 600 x 8mm 1200 x 600 x 12mm 1200 x 600 x 15mm
1800 x 600 x 8mm 1800 x 600 x 12mm 1800 x 600 x 15mm
2400 x 600 x 8mm 2400 x 600 x 12mm 2400 x 600 x 15mm
Thicknes: 8mm Thicknes: 12mm Thicknes: 15mm
Weight m2:    kgs Weight m2:    kgs Weight m2:    kgs

Ventilated Façade Solutions from Innowood & Allface

INNOWOOD in partnership with recognised market leaders in the international façade industry "Allface Smart Fixing Systems" provide complete ventilated façade solutions to the market. INNOWOOD's innovative composite timber cladding in conjunction with Allface Smart Fixing Systems provide the complete ventilated façade solution.

installation system

Anti rodent grid

Anti Rodent Grid( Bottom)

Air putout from chamber

Air Output From Chamber(Top)

Bracket

Bracket System

INNOWOOD Allface Ventilated Façade System - allows you to choose from an endless range of designs, Material and architectural features. It also offers intelligent solutions to meet any of your attachment requirements – visible or concealed, structurally bonded or mechanically fixed.

Benefits Of INNOWOOD Allface Ventilated Façade Systems

vc1

Cost Effective & Energy Savings

INNOWOOD Ventilated façade systems provide a highly energy efficient solution. Less heat absorption reduces the amount of heat that a building absorbs in hot weather conditions from the partial reflection of solar radiation by the outside façade.

vc2

Acoustic & Environment Protection

Ventilated façade systems provide an increase in the reflection of external noise, with a recent Australian project realising an average reduction of up to 8db. With the primary external noise sources affecting buildings being road traffic noise.

vc3

Comfort & Aesthetic

INNOWOOD Natural Ventilated façade systems improves the temperature creating a comfort inside the building. INNOWOOD offers a wide range of boards, colours and finishes which can add character to your building while improving overall aesthetics.

vc4
vc5
vc6

Thermal Insulation & Structural Integrity

In addition to the protection a second façade provides against rain and wind, the natural bottom – to – top airflow through the cavity assists in elimination of moisture accumulation on the facade, preventing water ingress, helping to prolong the structural integrity and ultimately the lifespan of a building.

INNOVATIVE & PREMIUM COLOUR RANGE

INNOWOOD pre-finished product comes in your choice of either INNOVATIVE or PREMIUM Colour Ranges.
The main difference is in the finish and visual grain structure. The Innovative Range has a brushed texture with a brushed coated linear grain finish;
whereas the Premium Range has a brushed finish but utilises the latest technology during the extrusion process to imitate a natural wood grain structure.

COLOURS & FINISHES

INNOVATIVE TEXTURE COLOUR RANGE

Colour Options – American Oak, Western Red Cedar, Spotted Gum, and Weathered Wood
Surface Finish - Brushed wood grain

PREMIUM TEXTURE COLOUR RANGE

Colour Options – Premium Oak, Golden Oak, Tasmanian Oak, and Kiwi Black
Surface Finish - Brushed wood grain

Colour Chart - PREMIUM RANGE

* Please bear in mind that colours may appear slightly different on delivery due to the lighting during photo shoot or different monitor settings.
