SHIPLAP CLADDING SYSTEM

INNOWOOD’s Shiplap Cladding System features an interlocking tongue and groove design to achieve concealed fixings while providing a conventional timber appearance with a warm, clean and durable finish. Consistently uniform shadow lines between the boards become architectural features when the boards are installed either horizontally or vertically.

V - JOINT SHIPLAP CLADDING

INNOWOOD’s V Joint Shiplap Cladding system comes in 25 mm thick boards with ‘V’ shaped tongue and groove shadow line rebated joints. INNOWOOD V Joint Shiplap boards overlap one another, concealing the fixing and locking in the boards to give a clean finish with effective board coverages of 105mm, 165mm and 205mm. These profiles can be mixed and matched to achieve varying board widths, creating a unique architectural feature.

CLADDING- SHIPLAP 1
WC13635P
WC20025P-w

PROFILES

WC13625PS-w
WC20025PS-w

PRODUCT CODES

WC13625

WC20025

COVERAGE

105mm

165mm

SPAN CENTERS

450mm

450mm

STANDARD LENGTH

4500mm

4500mm

INNOVATIVE COLOURS

Available

Available

PREMIUM COLOURS

Available

Available

CLADDING- SHIPLAP 2

SECRET FIXED SHIPLAP CLADDING SYSTEM

INNOWOOD Secret Fixed Shiplap Cladding system is available in board thicknesses of 33mm that delivers concave and convex shaped boards that utilises tongue and groove shadow line rebated joints. Our Secret Fixed Shiplap boards overlap one another concealing the fixing and locking in the boards to give a clean finish with board coverage of 150mm.

WC17735
WC20435

PROFILES

sh4
WC20435S

PRODUCT CODES

WC17533

WC20435

COVERAGE

150mm

180 mm

SPAN CENTER

450mm

450mm

STANDARD LENGTH

4500mm

4500mm

INNOVATIVE COLOURS

Available

Available

PREMIUM COLOURS

Available

Available

STARTER AND CORNER TRIM ANGLE

Starter and Corner Trim Angles are designed to control and conceal material movement, while simultaneously helping to keep the board secured in place and also to improve the appearance of the corners and edges providing a clean finish.

starter

BUTT JOINT CONTROL

INNOWOOD material much like natural timber expands and contracts with change in temperature, which is inevitable. INNOWOOD has developed the following options to control product movement at board ends and Butt joints :

BUTT JOINT

APPLICATIONS & BENEFITS

APPLICATIONS
  • Residential Applications
  • Commercial Applications
  • Health / Aged Care Facilities
  • Educational Institutions
  • Hospitality Sector
  • Retail & Shopping Centres
BENEFITS
  • Lightweight & Durable
  • Fire & Water Resistant
  • Natural Timber Look & Feel
  • Adds Warmth & Style
  • Enhances Aesthetic appeal
  • Variety of Colours & Finishes
  • Thermal & Acoustic Insulation
  • Fungous & Mould Resistant
  • Can be orientated Vertically or Horizontally

INNOVATIVE & PREMIUM COLOUR RANGE

INNOWOOD pre-finished product comes in your choice of either INNOVATIVE or PREMIUM Colour Ranges.
The main difference is in the finish and visual grain structure. The Innovative Range has a brushed texture with a brushed coated linear grain finish;
whereas the Premium Range has a brushed finish but utilises the latest technology during the extrusion process to imitate a natural wood grain structure.

COLOURS & FINISHES

INNOVATIVE TEXTURE COLOUR RANGE

Colour Options – American Oak, Western Red Cedar, Spotted Gum, and Weathered Wood.
Surface Finish - Brushed wood grain

Colour Chart - Innovative Rnage

PREMIUM TEXTURE COLOUR RANGE

Colour Options – Premium Oak, Golden Oak, Tasmanian Oak and Kiwi Black
Surface Finish - Brushed wood grain.

Colour Chart - PREMIUM RANGE

* Please bear in mind that colours may appear slightly different on delivery due to the lighting during photo shoot or different monitor settings.

INSTALLATION MANUALS & VIDEO GUIDES

* To ensure long-term performance we recommend that a professional trade person carry out the installation. The installation must be carried out in accordance with these instructions including the use of all trims and accessories.
